There are four basic types of motion in mechanical systems:

ROTARY MOTION is turning round in a circle;
LINEAR MOTION is moving in a straight line;
RECIPROCATING MOTION is moving backwards and forwards in a straight line;
OSCILLATING MOTION is swinging from side to side;



Many mechanical devices convert motion from one type to another. What is the input and output motion for the equipment given alongside? (See the arrows showing the direction and type of the input motion.)
